ITI Straumann Bone Level® Titanium Ti-Base Abutment Compatible
NC 3.3mm/ RC 4.1mm
Material:
Ti 6AI-4V ELI (Supply from Germany)
Feature:
* Titanium interface abutment
* 1pc Screw Included
* Precision machined up to ± 5µm
* Combination of high fatigue strength
* Superior level of biocompatibility
* Exterior retentions for more cementation bonding
Specific design ensures a stable union, reinforcing the structure of zirconium in the areas of greatest stress, softening edges and ensuring the service life of the prosthesis.
Furthermore, the saving is also shown in the less time needed when working on the most sensitive part of the prosthesis, the adjustment with the implant.
Approved by CE, ISO 9001, ISO 13485
| TI BASE | A | B | C | D |
| 15.043 | NP (NC) | Non-engaging | 2,75 | Circular | 0,20 | 4,50 |
| 15.343 | NP (NC) | Non-engaging | | | | |
| 16.043 | NP (NC) | Engaging | 2,75 | Conical BL | 0,20 | 4,50 |
| 16.343 | NP (NC) | Engaging | | | | |
| 15.044 | RP (RC) | Non-engaging | 3,30 | Circular | 0,20 | 4,90 |
| 15.344 | RP (RC) | Non-engaging | | | | |
| 16.044 | RP (RC) | Engaging | 3,30 | Conical BL | 0,20 | 4,90 |
| 16.344 | RP (RC) | Engaging | | | | |
| 15.098 | NP (NC)/RP (RC) | Non-engaging | | | | |
| 16.098 | NP (NC)/RP (RC) | Engaging | | | | |
Product Description
ITI Straumann Bone Level® Titanium Ti Base Abutment are prefabricated, screw-retained intraoral abutments designed to be connected directly to an endosseous implant for retention of a cemented dental prosthesis. They may be used for single- and multiple-tooth restorations. ITI Straumann Bone Level® Titanium Ti Base Abutment are precisely machined from titanium alloy and attached to the implant fixture with a titanium screw. For use in any region of the mouth, they contain a standard. Each abutment is specific to the restorative platform of the seated implant.
Accessories
Titanium screw.
Contraindications
The following conditions would contraindicate use of Inclusive Titanium Abutments: (a) wall thickness less than 0.5 mm; (b) gingival margin diameter less than 0.5 mm wider than the implant; (c) angle corrections of more than 30 degrees; (d) less than 0.5 mm margin height; (e) less than 4.0 mm abutment height.
Sterility
ITI Straumann Bone Level® Titanium Abutments are packaged NON-STERILE. Prior to use in the oral environment, they should be cleaned, disinfected, and sterilized firstly.
